Cadre
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | RIDE-4™ Adjustable Geometry | 120mm Travel. FORM™ Alloy Rear Triangle
Fourche
Fox 34 Float Performance 130mm | 44mm Offset
Débattement avant
130mm
Amortisseur
Fox Float DPS Performance | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 190x45mm | Size-Specific tune in FAQ
Débattement arrière
120mm
Jeu de direction
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Potence
Rocky Mountain 31.8 XC | 5° Rise | All Sizes = 50m
Cintre
Rocky Mountain AM | XS = 760mm | SM - XL = 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Poignets
ODI Elite Pro Lock On
Freins
Shimano SLX 2 Piston | Resin Pads | F:Shimano RT64 180mm | R:Shimano RT64 180mm
Commandes de vitesses
Shimano SLX
Derailleur arrière
Shimano XT
Pédalier et plateau
Race Face Aeffect Cinch | 32T Steel | 24mm Spindle | Crankarm Length: XS = 165mm Crankarm | SM - XL = 170mm
Boitier de pédalier
Shimano SM-BBMT500
Cassette
Shimano SLX 10-51T
Chaine
Shimano M7100
Moyeux avant
Rocky Mountain Sealed Boost 15mm
Moyeux arrière
Shimano SLX Boost 148mm
Rayons
DT Swiss Competition 2.0/1.8/2.0
Jantes
WTB ST Light i27 TCS 2.0 Tubeless | 28H | Tubeless Ready - Tape / Valves Incl
Pneus
F: Maxxis Rekon 2.4 WT EXO Tubeless Ready // R: Maxxis Rekon 2.4 WT EXO Tubeless Ready
Tige de selle
Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm
Selle
WTB Volt Race 142
